Ostrich ELAN EX Electric Wheelchair Material Aluminum alloy body with a Maximum load capacity of up to 100 kg. powered with a motor DC 24V 180W*2. Most light Electric Wheelchair recommended to use for indoor purposes and as transfer wheelchairs where extensive travel is there
Ostrich ELAN EX Electric Wheelchair Specification
Technical Specification
- Load capacity: 130 Kg /286 lbs
- Speed:9 km/H max
- Speed selection: 5 speeds
Features
- Model / Parameter WX-A02 Material Aluminum alloy
- Maximum load (kg) ≤100 kg
- Folded size 590*420*740mm Maximum s
- peed ≤6 km/h Braking distance ≤1.5m Battery weight 1.5KG*2
- Maximum safe slope braking ≤1.6m 3º
- Slope performance 9º
- Static stability ≥9º Obstacle height ≥30mm
- Maximum climb ≤12º
- Minimum turning radius 1M
Motor
- Motor power (VA) DC 24V 180W*2
Tyre & Battery
- Front-wheel: 10 inches PU tire
- Rear-wheel: 7 inches PU tire
- Battery: 24V 6AH*2 lithium battery
>
Dimensions
- Seat (depth* width* height) – 440*460*470mm
- Seat height off the ground 470m
Controller
- 360-degree control direction (left and right hands are interchangeable)
- Drive System 2*180W dual-motor rear-drive
- Brake system Electric brake
