Olex DVT Pump with Sleeves

OLEX DVT Pump is a lightweight compression pump for Deep Vein Thrombosis (DVT) therapy. The Olex DVT Pump aids in the prevention of deep vein thrombosis (DVT) through a compression system that consists of a DVT pump and DVT sleeves. DVT Pump provides calf and thigh compression for DVT therapy which increases blood velocity in the deep veins, reducing stasis and stimulating fibrinolysis to prevent and break down clots.

TECHNICAL SPECIFICATIONS

• Size: 6.5” L x 7.£f” W x 12.8” H
• Weight: 2.5kg
• Pressure Settings:

Calf/Thigh sleeve: 30, 40 (default), 50, 60 mmHg; +10/-5mmHg

Foot sleeve: 120 mmHg ; +10/-5mmHg

• Input Rating: AC 100V-240V 50/60 Hz, 0.2A-0.SSA
• Fuse Rating: 1A, 250V
• Appliance Class: Class I, Type BF

• Not AP or AGP type
• Classification to FDA: Class II
• Classification to CDSCO: Class B
• Humidity: Operation 30% to 75 %
• Storage & Transportation 30% to 75%
• Air pressure: 4 — 16 kPA
• Temperature: Operation 15° – 35° C
• Storage & Transportation 5-60 degrees C
• Cycle Time: Inflation 12 seconds +/- 10%
• Deflation: 48 seconds +/- 10%

How TO Use DVT Pump?

1. Wrap the sleeves around the patient’s legs
2. Connect the extension hoses to the pump and sleeves
3. Connect the pump to mains power and switch on the mains switch
4. Power on the pump by long pressing the power button
5. After sleeve checking, inflation will start

In The Box

• Olex DVT Pump
• Calf Sleeves
• User Manual
• Power Cord

Warranty – 1 Year

Country Of Origin- China
